6A à souder anneau d'accouplement

Le 6A Weld-On anneau d'accouplement de Premier est un ajout remarquable à votre arsenal de camionneur. Il est parfait pour tirer jusqu'à 100 000 livres de poids de remorque ! Consultez le guide d'installation ci-dessous pour plus d'informations. Trouvez un distributeur dès aujourd'hui !

Description

MODÈLES

Modèle nRéférenceDescription
6A10000841anneau d'accouplementà souder, 2 3/8" ID

PIÈCES ACCESSOIRES

Modèle nRéférenceDescription
1403210000075Jauge d'usure

SPÉCIFICATIONS

Poids maximal de la langue6 804 kg (15 000 lb)
Poids brut maximal de la remorque100 000 livres. (45 359 kg)
Diamètre intérieur2 3/8 in. (60 mm)
Poids unitaire18,9 lb (8,6 kg)
  • Accessoires pour camions personnalisés

    Jauges d'usure

    <span data-sheets-value="{"1":2,"2":"To determine wear limits, Premier Manufacturing created wear gages that help judge the useful life of couplings, pintle hitches, and drawbar eyes. Available as a complete kit or individually, these gages are easy to use and are a must for maintenance managers and safety personnel.\nIn accordance with Premier Manufacturing and the Federal Motor Carrier Safety Regulations, these were ...

Vous trouverez ci-dessous la liste des produits compatibles attelages. Pour consulter le tableau de référence complet, cliquez ici.
